Description
| Model | XQ35 PRO |
| SKU | 76541 |
| Microbolometer | |
| Type | uncooled |
| Resolution, pixels | 384×288 |
| Pixel Pitch, µm | 17 |
| NETD, mK | < 25 |
| Frame refresh rate, Hz | 50 |
| Optical Specifications | |
| Lens, mm | F35 F/1.0 |
| Magnification, x | 2.5-10 |
| Eye relief, mm/inch | 50/1.96 |
| Field of view (H), °/m@100 | 10.7/18.7 |
| Diopter adjustment, D | -3/+5 |
| Detection distance (Object of “deer” type), m/y | 1350/1476 |
| Aiming Reticle | |
| Click value, mm@100 m – when magnifying, x | 18.2 mm – 2.5x 9.1 mm – 5x 4.6 mm – 10x |
| Click range (H/V), mm@100 m (H/V) | 3600/3600 |
| Display | |
| Type | AMOLED |
| Resolution, pixels | 1024х768 |
| Operating Features | |
| Diameter of the riflescope body to assemble the mounting rings, mm | 30 |
| Power Supply, V | 3–4.2 |
| Battery type / Capacity / Rated Output Voltage | Li-Ion Battery Pack АPS2 / 2000 mAh / DC 3.7 V (removable) or Li-Ion Battery Pack APS3 / 3200 mAh / DC 3.7 V (removable)*
Li-Ion Battery Pack APS5 / 4900 mAh / DC 3.7 V (built-in) |
| External Power Supply | 5 V, 9 V (USB Type-C Power Delivery) |
| Battery Packs (built-in APS5 and removable APS2) operating time at temp. = 22 °C, hrs** | 10 |
| Max. recoil power on rifled weapon, Joules | 6000 |
| Max. recoil power on smoothbore weapon, caliber | 12 |
| Degree of protection IP code (IEC60529) | IPX7 |
| Operating temperature, °С / °F | -25 – +50 / -13 – +122 |
| Dimensions with an eyecup, mm/inch | 399х78х80 / 15.7×3.07×3.15 |
| Weight (without removable battery), kg/oz | 0.88 / 31.04 |
| Video Recorder | |
| Photo / video resolution, pixels | 1024×768 |
| Video / photo format | .mp4 / .jpg |
| Built-in memory | 16 GB |
| Wi-Fi Channel*** | |
| Frequency | 2.4/5 GHz |
| Standard | IEEE 802.11 b/g/n/ac |
* Purchased separately.
** Actual operating time will depend to what extent the Wi-Fi and built-in video recorder is used.
*** The reception range may vary depending on various factors: obstacles, other Wi-Fi networks.
