Description
Specialist scopes designed by airgunners for airgunners!
Airmax scopes feature our H2 optics in a variety of configurations designed to suit airgun characteristics.
- Capped Target Turrets
- 30mm Mono-Tube Chassis
- Wide Angle
- Side Focus
- Illumination
- 16 Layer Fully Multi-Coated Lenses
- High Torque Zoom Ring
- Fast Focus Eyebell
- AMX Reticle Designed For Airguns
Nitrogen purged. Shockproof. Waterproof. Fog proof.
All calibre rated.
Hawke Warranty.
AMX Reticle
Both the AMX and AMX IR glass etched reticles are based on the spacing of a 10x Mil Dot. The AMX offers multiple aim points, useful when shooting air guns with loopy trajectories.
Half Mil Dot spacing on the lower post provides increased aim points for long shots.
The horizontal bars are calculated at 0.5, 1.5, 2.5, 3.5 and 4.5 mil spacing. Hollow posts are segmented into mil spacing and can be used for bracketing.
Length:
378mm
14.9″
Weight:
770g
27.2oz
Eye relief:
102mm
4″
Focus/Parallax – Side Focus
9m – ∞
10yds – ∞
Field of View:
6.8-1.7m @100m
20.3-5.1ft @100yds
Exit Pupil:
8.3-2.1mm
0.33-0.08″
Chassis
30mm Mono-tube
Optical System
6-24x
Objective
50mm
Illumination
Red (6 Levels With Off Positions In-Between)
Reticle
AMX IR
Elevation Increment
1⁄10 MRAD
Elevation Adjustment Range:
17 MRAD
Windage Increment
1⁄10 MRAD
Windage Adjustment Range
17 MRAD
Material
Aluminium
Ocular Type
Fast Focus
Lens Coating
Fully Multi-Coated – 16 Layers
Power Selector Style
Knurled Posi-Grip
Focal Plane
Second Focal Plane (SFP)
Turret Caps
Yes
Turret Type
Capped Target Turrets
