Description
Airmax scopes feature our H2 optics in a variety of configurations designed to suit airgun characteristics.
- Capped Target Turrets
- 30mm Mono-Tube Chassis
- Wide Angle
- Side Focus
- Illumination
- 16 Layer Fully Multi-Coated Lenses
- High Torque Zoom Ring
- Fast Focus Eyebell
- AMX Reticle Designed For Airguns
Nitrogen purged. Shockproof. Waterproof. Fog proof.
All calibre rated.
Hawke Warranty.
AMX Reticle
Both the AMX and AMX IR glass etched reticles are based on the spacing of a 10x Mil Dot. The AMX offers multiple aim points, useful when shooting air guns with loopy trajectories.
Half Mil Dot spacing on the lower post provides increased aim points for long shots.
The horizontal bars are calculated at 0.5, 1.5, 2.5, 3.5 and 4.5 mil spacing. Hollow posts are segmented into mil spacing and can be used for bracketing.
Objective Lens 50mm
Reticle AMX IR
Parallax Side Focus
Magnification 4 – 16x
Optical System System H2
Focal Plane SFP (Second Focal Plane)
Scope Tube 30mm
Illumination 6 Levels with Off Positions In-between – Red
Field of View 30.7 – 7.7ft @100yds 10.2 – 2.6m @100m
Field of View 5.8 – 1.5°
Eye Relief 4in 102mm
PX/Focus(Error free from)
10yds – ∞
9m – ∞
Exit Pupil
0.49 – 0.12″
12.5 – 3.1mm
Turret Type Target
Turret Caps YES
Click Value 1⁄ 10MRAD
Elevation Turret Clicks (max) 27 MRAD
Windage Turret Clicks (max) 27 MRAD
Ocular Type Fast Focus
Power Selector Rubber Coated Posi-Grip
Lens Coating Fully Multi-Coated – 16 Layers
Length 13.7″ 348mm
Weight 26.8oz 760g
